DS1248W-120IND Overview
The package 32-DIP Module (0.600, 15.24mm) contains real time clocks.The package is in the form of Bulk.This electrical RTC has a supply voltage of 2.97V ~ 3.63V.This electrical real time clock has the type Phantom Time Chip.Through Hole is the way this real time clock (RTC) is mounted.Electronic time clocks are recommended that the operating temperature be -40°C ~ 85°C.This electrical digital time clock has a - supply voltage.For storing data and programs, the RTC times embed a memory of 128KB.Through Hole is the mounting type of the RTC module.It is equipped with 32 pins.In order to achieve high efficiency, the supply voltage should be kept at 3.3 V.Ideally, the operating temperature should be higher than -40 °C.Ideally, the operating temperature should be lower than 85 °C.The minimal supply voltage is 2.97 V.A maximum supply voltage of 3.63 V is used.It is a type of real time clock belonging to the - series.120 GHz is the maximum frequency that can be achieved.
DS1248W-120IND Features
32-DIP Module (0.600, 15.24mm) package
Be maintained at 3.3 V for high efficiency.
- series

DS1248W-120IND Applications
There are a lot of Analog Devices
DS1248W-120IND Real Time Clocks applications.

Portable instruments
Electronic metering
Battery powered products
Automotive
Industrial
Digital still camera
Digital video camera
Printers
Copy machines
Mobile equipment

Mounting Type	Through Hole
Package / Case	32-DIP Module (0.600, 15.24mm)
Mount	Through Hole
Number of Pins	32
Supplier Device Package	32-EDIP
Package	Tube
Base Product Number	DS1248
Mfr	Analog Devices Inc./Maxim Integrated
Product Status	Obsolete
RoHS	Compliant
Operating Temperature	-40°C ~ 85°C
Series	-
Packaging	Bulk
Type	Phantom Time Chip
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Voltage - Supply	2.97V ~ 3.63V
Frequency	120 GHz
Operating Supply Voltage	3.3 V
Interface	Parallel
Max Supply Voltage	3.63 V
Min Supply Voltage	2.97 V
Memory Size	128KB
Access Time	120 ns
Logic Function	Clock
Time Format	HH:MM:SS:hh (12/24 hr)
Date Format	YY-MM-DD-dd
Current - Timekeeping (Max)	7mA @ 3.3V
Voltage - Supply, Battery	-
Features	NVSRAM
Radiation Hardening	No
Lead Free	Contains Lead
