The STR-A6000 series are power ICs for switching power supplies, incorporating a MOSFET and a current mode PWM controller IC. The low standby power is accomplished by the automatic switching between the PWM operation in normal operation and the burst-oscillation under light load conditions. The product achieves high cost-performance power supply systems with few external components.
| Manufacturer | Sanken |
| Product Category | AC DC Converters, Offline Switchers |
| Series | STR-A6000 |
| Packaging | Tube |
| Package-Case | 8-DIP (0.300", 7.62mm), 7 Leads |
| Operating-Temperature | -20°C ~ 125°C (TA) |
| Mounting-Type | Through Hole |
| Supplier-Device-Package | 8-DIP |
| Watt | 35W |
| Output-Isolation | Isolated |
| Internal-Switch-s | Yes |
| Voltage-Breakdown | 700V |
| Topology | Flyback |
| Voltage-Start-Up | 15.3V |
| Voltage-Supply-Vcc-Vdd | 8.1 V ~ 32 V |
| Duty-Cycle | 83% |
| Frequency-Switching | 100kHz |
| Fault-Protection | Current Limiting, Over Load, Over Temperature, Over Voltage |
| Control-Features | - |
