74VCX16501MTDX Overview
There is an embedded version of it in the 56-TFSOP (0.240, 6.10mm Width) package. In this case, it is packaged in the same way as Tape & Reel (TR). The superior flexibility of this circuit is achieved through the use of 18-Bit circuits. There is a logic type Universal Bus Transceiver associated with this electrical device. It is mounted in the way of Surface Mount so that this electronic part can be seen. It is better to have an operating temperature higher than -40°C~85°C. In order to ensure maximum design flexibility, it features a High/Low output current of 24mA 24mA. It is a type of FPGA that belongs to the 74VCX series of FPGAs. It operates at a voltage of 1.4V~3.6V. It is a member of the 74VCX16501 family. Mounted in the way of Surface Mount is this electronic part. 56 pins are used in the design. The element consists of 1 elements in total. Channel growth is strong/weak according to the following indicator: 18. In this case, 56-TSSOP is the supplier device package that the company is using. A minimal supply voltage of 1.4V is required for it to operate. As a result, it supports the maximum supply voltage of 3.6V. There is a high level output current called 24mA. A higher operating temperature is recommended than -40°C. Operating temperatures should ideally be lower than 85°C.
74VCX16501MTDX Features
56-TFSOP (0.240, 6.10mm Width) package
74VCX series
74VCX16501 family
56 pins
1 elements

74VCX16501MTDX Applications
There are a lot of ON Semiconductor
74VCX16501MTDX Universal Bus Functions applications.

Instrumentation Systems
Air conditioner
Home theater
Electric grinding wheel
Electrical tools
Sewing machine
DVD
VCD
Computer
Television

Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	56-TFSOP (0.240, 6.10mm Width)
Number of Pins	56
Supplier Device Package	56-TSSOP
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
Series	74VCX
Published	2004
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Voltage - Supply	1.4V~3.6V
Base Part Number	74VCX16501
Number of Elements	1
Polarity	Non-Inverting
Number of Channels	18
Number of Circuits	18-Bit
Max Supply Voltage	3.6V
Min Supply Voltage	1.4V
Propagation Delay	8.8 ns
Turn On Delay Time	19.6 ns
Logic Function	Transceiver
Current - Output High, Low	24mA 24mA
Logic Type	Universal Bus Transceiver
High Level Output Current	24mA
Low Level Output Current	24mA
RoHS Status	RoHS Compliant
Lead Free	Lead Free
Package	Bulk
Base Product Number	74VCX16501
Mfr	Fairchild Semiconductor
Product Status	Obsolete
Operating Temperature	-40°C ~ 85°C
Voltage - Supply	1.4V ~ 3.6V
Current - Output High, Low	24mA, 24mA
