| Manufacturer | Power Integrations |
| Product Category | AC DC Converters, Offline Switchers |
| Series | TOPSwitch®-HX |
| Type | Off Line Switcher |
| Packaging | Tube |
| Mounting-Style | Through Hole |
| Tradename | TopSwitch |
| Operating-Temperature-Range | - 40 C to + 150 C |
| Package-Case | 7-SIP, 6 Leads, Exposed Pad, Formed Leads |
| Operating-Temperature | -40°C ~ 150°C (TJ) |
| Mounting-Type | Through Hole |
| Supplier-Device-Package | eSIP-7F |
| Watt | 244W |
| Number-of-Outputs | 1 Output |
| Output-Isolation | Isolated |
| Internal-Switch-s | Yes |
| Voltage-Breakdown | 700V |
| Topology | Flyback |
| Voltage-Start-Up | - |
| Voltage-Supply-Vcc-Vdd | - |
| Duty-Cycle | 78% |
| Frequency-Switching | 66kHz, 132kHz |
| Fault-Protection | Current Limiting, Over Temperature, Over Voltage |
| Control-Features | - |
| Output-Power | 177 W |
| Maximum Operating Temperature | + 150 C |
| Output-Voltage | 12 V |
| Operating-Supply-Current | 1.6 mA |
| Switching-Frequency | 132 kHz |
| Package-Case | eSIP-7F |
| Duty-Cycle-Max | 83 % |
| Input-Supply-Voltage-Min | 85 VAC |
| Input-Supply-Voltage-Max | 265 VAC |
