ADM6996IX-AD-T-1 OverviewThere is a copy of it in the 128-BFQFP package. It is easy to carry thanks to its Tray-shaped packaging. A temperature of 0°C~115°C should be maintained for reliable operation. The 2.8V~3.465VV power source is all you need to use it. The terminations in it can be broken down into 128's. Providing a voltage of 1.8V leads to high efficiency. There are two ADM6996s in the number. In order for the device to function, 128 pins must be used. SERIAL IO/COMMUNICATION CONTROLLER, LAN uPs, uCs, and peripheral ICs are present in this gadget. The device runs at a frequency of 25MHz, which is determined by its clock. There are 7 serial I/Os incorporated in the part. Additionally, the ALSO REQUIRES 3.3V SUPPLY number can be generated with this device.
ADM6996IX-AD-T-1 Features25MHz clock frequency
ADM6996IX-AD-T-1 ApplicationsThere are a lot of Infineon Technologies
ADM6996IX-AD-T-1 Controllers Interface ICs applications.
Dimming Control Devices
Commercial LED Lighting
Smart LED Lighting
Portable Appliances
Battery-Operated Devices
Cellular Data Devices
Factory Automation and Process Controls
IrDA transmission control
Remote transmission formatter
Docking
Package / Case | 128-BFQFP |
Surface Mount | YES |
Number of Pins | 128 |
Operating Temperature | 0°C~115°C |
Packaging | Tray |
Published | 2007 |
JESD-609 Code | e3 |
Part Status | Obsolete |
Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
Number of Terminations | 128 |
Terminal Finish | MATTE TIN |
Additional Feature | ALSO REQUIRES 3.3V SUPPLY |
HTS Code | 8542.31.00.01 |
Voltage - Supply | 2.8V~3.465V |
Terminal Position | QUAD |
Terminal Form | GULL WING |
Peak Reflow Temperature (Cel) | 260 |
Supply Voltage | 1.8V |
Terminal Pitch | 0.5mm |
Time@Peak Reflow Temperature-Max (s) | 40 |
Base Part Number | ADM6996 |
Function | Switch |
Qualification Status | Not Qualified |
Interface | Parallel |
uPs/uCs/Peripheral ICs Type | SERIAL IO/COMMUNICATION CONTROLLER, LAN |
Clock Frequency | 25MHz |
Protocol | Ethernet |
Boundary Scan | NO |
Low Power Mode | YES |
Number of Serial I/Os | 7 |
Standards | 10/100 Base-T/TX PHY |
Data Transfer Rate-Max | 12.5 MBps |
Data Encoding/Decoding Method | NRZ; NRZI |
Length | 20mm |
Height Seated (Max) | 3.4mm |
Width | 14mm |
RoHS Status | RoHS Compliant |
EU RoHS | Compliant |
Automotive | Unknown |
PPAP | Unknown |
Part Status | Unconfirmed |
