BD3814FV-E2 Overview
In addition, the book comes with a case study as well. It is recommended that you mount it in a Surface Mount mounting type. Case 40-SSOP contains it. There are 6 channels on the device. The Audio Signal Processor functions in this part are included for your reference. There is a Consumer Audio version of the device. There is a supply of votage within 5V~7.3V days of ordering. With this device, you can operate the temperature within a range of -20°C~75°C TA. 40 terminations are present on the chip. By searching for BD3814 family parts, similar parts can be found. For more information, please refer to the device specs: 132dB. To sort IC types, use TONE CONTROL CIRCUIT. There should be no voltage below 5V on the supply line of this component (Vsup). The voltage it can produce is +-7V volts. When Vsup reaches 7.3V, the maximum supply voltage (Vsup) is reached. As seen in the picture, Surface Mount is mounting it. 2 bands are present on it. The current supply is controlled by 17mA.
BD3814FV-E2 Features
With 40-SSOP channels
operate temperature at the range of -20°C~75°C TA
consumer IC type: TONE CONTROL CIRCUIT

BD3814FV-E2 Applications
There are a lot of ROHM Semiconductor
BD3814FV-E2 Audio Special Purpose applications.

Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
Distribution Amplifiers
Graphic and P arametric Equalizers
Dynamic Range Processors

Factory Lead Time	8 Weeks
Contact Plating	Copper, Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	40-SSOP
Operating Temperature	-20°C~75°C TA
Packaging	Tape & Reel (TR)
Published	2010
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	40
ECCN Code	EAR99
Applications	Consumer Audio
HTS Code	8542.39.00.01
Voltage - Supply	5V~7.3V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	BD3814
JESD-30 Code	R-PDSO-G40
Function	Audio Signal Processor
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	7.3V
Power Supplies	+-7V
Supply Voltage-Min (Vsup)	5V
Number of Channels	6
Interface	Serial
Supply Current-Max	17mA
Specifications	132dB
Consumer IC Type	TONE CONTROL CIRCUIT
Number of Bands	2
Harmonic Distortion	0.001%
Channel Separation	95 dB
Height Seated (Max)	1.9mm
Width	5.4mm
RoHS Status	ROHS3 Compliant
Mfr	Rohm Semiconductor
Series	-
Product Status	Active
Voltage - Supply	5V ~ 7.3V
Operating Temperature	-20°C ~ 75°C (TA)
Package / Case	40-SSOP (0.213", 5.40mm Width)
Supplier Device Package	40-SSOP-B
