BD3884FS-E2 Overview
This item comes with a case that goes with it. The mounting type that is recommended is Surface Mount. The embedded file is in the 24-SOP (0.213, 5.40mm Width) case. The device has a 2 channel. Here is a list of Audio Signal Processor functions for your reference. There is the possibility of applying the device in Consumer Audio. There is a delivery within 7V~9V of the votage. In this device, temperature is measured in the -40°C~85°C TA range. On the chip, 24 terminations are present. If you search for the BD3884 family, you will find similar parts. Here are the device specifications: Front End. Sorting by TONE CONTROL CIRCUIT can be done to find out the type of consumer IC in the part. It is recommended that the minimum supply voltage (Vsup) for this part be higher than 7V. At 9V volts, it can provide voltage. It reaches 9.5V when the maximum supply voltage (Vsup) is reached. As you can see, Surface Mount has mounted it. On it, there are 2 bands.
BD3884FS-E2 Features
With 24-SOP (0.213, 5.40mm Width) channels
operate temperature at the range of -40°C~85°C TA
consumer IC type: TONE CONTROL CIRCUIT

BD3884FS-E2 Applications
There are a lot of ROHM Semiconductor
BD3884FS-E2 Audio Special Purpose applications.

Car or Mobile Audio System
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
Distribution Amplifiers

Factory Lead Time	7 Weeks
Contact Plating	Copper, Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	24-SOP (0.213, 5.40mm Width)
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Published	2005
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	24
ECCN Code	EAR99
Applications	Consumer Audio
Voltage - Supply	7V~9V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Terminal Pitch	0.8mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	BD3884
Function	Audio Signal Processor
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	9.5V
Power Supplies	9V
Supply Voltage-Min (Vsup)	7V
Number of Channels	2
Interface	I2C
Specifications	Front End
Consumer IC Type	TONE CONTROL CIRCUIT
Number of Bands	2
Harmonic Distortion	0.008%
Channel Separation	80 dB
Length	10mm
Height Seated (Max)	1.9mm
Width	5.4mm
RoHS Status	ROHS3 Compliant
Mfr	Rohm Semiconductor
Series	-
Product Status	Obsolete
Interface	I²C
Voltage - Supply	7V ~ 9V
Operating Temperature	-40°C ~ 85°C (TA)
Package / Case	24-SOP (0.213", 5.40mm Width)
Supplier Device Package	24-SSOP-A
