CS8416-CZZ Overview
In addition, the book comes with a case study as well. It is recommended that you mount it in a Surface Mount mounting type. Case 28-TSSOP (0.173, 4.40mm Width) contains it. There are 8 channels on the device. The Audio Receiver functions in this part are included for your reference. There is a Digital Audio Interfacing version of the device. There is a supply of votage within 3.3V~5V days of ordering. With this device, you can operate the temperature within a range of -10°C~70°C TA. By searching for CS8416 family parts, similar parts can be found. For more information, please refer to the device specs: 32kHz ~ 192kHz. 28 pins are available on the chip. To sort IC types, use CONSUMER CIRCUIT. The voltage it can produce is 3.33.3/5V volts. When Vsup reaches 3.46V, the maximum supply voltage (Vsup) is reached. The supply current is 11.8mA and it operates at a voltage of 11.8mA volts.
CS8416-CZZ Features
With 28-TSSOP (0.173, 4.40mm Width) channels
operate temperature at the range of -10°C~70°C TA
consumer IC type: CONSUMER CIRCUIT
operate supply current at 11.8mA

CS8416-CZZ Applications
There are a lot of Cirrus Logic Inc.
CS8416-CZZ Audio Special Purpose applications.

Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
Distribution Amplifiers
Graphic and P arametric Equalizers
Dynamic Range Processors

Factory Lead Time	18 Weeks
Mounting Type	Surface Mount
Package / Case	28-TSSOP (0.173, 4.40mm Width)
Surface Mount	YES
Number of Pins	28
Weight	402.988471mg
Operating Temperature	-10°C~70°C TA
Packaging	Tube
Published	2001
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Termination	SMD/SMT
Terminal Finish	MATTE TIN
Applications	Digital Audio Interfacing
Voltage - Rated DC	3.3V
Voltage - Supply	3.3V~5V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Terminal Pitch	0.65mm
Current Rating	2.8mA
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	CS8416
Function	Audio Receiver
Supply Voltage-Max (Vsup)	3.46V
Power Supplies	3.33.3/5V
Number of Channels	8
Interface	I2C, SPI
Operating Supply Current	11.8mA
Nominal Supply Current	11.8mA
Logic Function	Receiver
Specifications	32kHz ~ 192kHz
Min Dual Supply Voltage	3.13V
Consumer IC Type	CONSUMER CIRCUIT
Number of Amplifiers	1
Length	9.7mm
Width	4.4mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	RoHS Compliant
Lead Free	Lead Free
Mfr	Cirrus Logic Inc.
Series	-
Product Status	Obsolete
Interface	I²C, SPI
Voltage - Supply	3.3V ~ 5V
Operating Temperature	-10°C ~ 70°C (TA)
Package / Case	28-TSSOP (0.173", 4.40mm Width)
Supplier Device Package	28-TSSOP
