CY7C63001C-SXCT OverviewThe outstanding performance of USB Microcontroller makes it an excellent choice.There is a 20-SOIC (0.295, 7.50mm Width) package available to save space.The way of Surface Mount is used to mount it.Application Specific Microcontroller comes in a Tape & Reel (TR) package.A M8A core processor powers the device.When working, the temperature should be kept at 0°C~70°C.OTP (4kB) is its program memory type.Application Specific Microcontroller is possible to achieve high efficiency wApplication Specific Microcontrollerh a 4V~5.25V supply voltage.There are 12 I/Os on it.A comparable component can be found by using the base part number CY7C63001.The terminals of this device are located at DUAL.It is a part of the series of controllers CY7C630xx.Application Specific Microcontroller has 20 terminations.The M8™ series includes this electrical component.The supply voltage of 5V allows for high efficiency.Memory type EPROM, OTP is used for data storage.As for the uPs/uCs/peripheral ICs, this gadget has MICROCONTROLLER, RISC.Application Specific Microcontroller is constructed using 20 pins.This mount is done in accordance with the method of Surface Mount.There are a total of 20 pins on it.Using the devices' 4kB memory size, you can store programs and data.The core architecture of the system is M8C.The maximum supply current is 25mA.Power comes from a source of 5V.At a frequency of 12MHz, it can achieve excellent efficiency.The supply voltage of 5V's adaptability can be fully utilised by designers.1 timers/counters are in use.
CY7C63001C-SXCT Features20-SOIC (0.295, 7.50mm Width) package
Mounting type of Surface Mount
CY7C63001C-SXCT ApplicationsThere are a lot of Cypress Semiconductor Corp
CY7C63001C-SXCT Microcontroller applications.
Equipment control
Instrument control
Instrument control
Toys
Robots
Radio
Television
Heater/Fan
Calculator
Kindle
| Mount | Surface Mount |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295, 7.50mm Width) |
| Number of Pins | 20 |
| Operating Temperature | 0°C~70°C |
| Packaging | Tape & Reel (TR) |
| Series | M8™ |
| Published | 2003 |
| JESD-609 Code | e4 |
| Part Status | Obsolete |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Number of Terminations | 20 |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Applications | USB Microcontroller |
| Voltage - Supply | 4V~5.25V |
| Terminal Position | DUAL |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Supply Voltage | 5V |
| Reach Compliance Code | unknown |
| Frequency | 12MHz |
| Time@Peak Reflow Temperature-Max (s) | 20 |
| Base Part Number | CY7C63001 |
| Pin Count | 20 |
| Qualification Status | Not Qualified |
| Operating Supply Voltage | 5V |
| Power Supplies | 5V |
| Interface | USB |
| Memory Size | 4kB |
| Number of I/O | 12 |
| RAM Size | 128 x 8 |
| Memory Type | EPROM, OTP |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER, RISC |
| Core Processor | M8A |
| Program Memory Type | OTP (4kB) |
| Supply Current-Max | 25mA |
| Bit Size | 8 |
| Access Time | 12 μs |
| Has ADC | NO |
| DMA Channels | NO |
| Data Bus Width | 8b |
| PWM Channels | NO |
| DAC Channels | NO |
| Number of Timers/Counters | 1 |
| ROM (words) | 4096 |
| Core Architecture | M8C |
| ROM Programmability | OTPROM |
| Controller Series | CY7C630xx |
| Height Seated (Max) | 2.667mm |
| RoHS Status | ROHS3 Compliant |
| Lead Free | Lead Free |
| Supplier Device Package | 20-SOIC |
| Package | Tape & Reel (TR) |
| Base Product Number | CY7C63001 |
| Mfr | Infineon Technologies |
| Product Status | Obsolete |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 4V ~ 5.25V |
