DIT4096IPWR Overview
This item comes with a case that goes with it. The mounting type that is recommended is Surface Mount. The embedded file is in the 28-TSSOP (0.173, 4.40mm Width) case. The device has a 1 channel. Here is a list of Line Driver functions for your reference. There is the possibility of applying the device in Pre-Amplifier, Professional Audio. There is a delivery within 4.5V~5.5V of the votage. In this device, temperature is measured in the -40°C~85°C TA range. On the chip, 28 terminations are present. If you search for the DIT4096 family, you will find similar parts. Here are the device specifications: Differential Output. The chip contains 28 pins. Sorting by CONSUMER CIRCUIT can be done to find out the type of consumer IC in the part. At 5V volts, it can provide voltage. When the chip's supply voltage is 5V, it conducts. This device also allows you to find ALSO REQUIRES 2.7V TO 5.5V SUPPLY. A supply current of 22mA is used to operate it.
DIT4096IPWR Features
With 28-TSSOP (0.173, 4.40mm Width) channels
operate temperature at the range of -40°C~85°C TA
consumer IC type: CONSUMER CIRCUIT
operate supply current at 22mA

DIT4096IPWR Applications
There are a lot of Texas Instruments
DIT4096IPWR Audio Special Purpose applications.

Car or Mobile Audio System
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
Distribution Amplifiers

Lifecycle Status	ACTIVE (Last Updated: 1 week ago)
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	28-TSSOP (0.173, 4.40mm Width)
Surface Mount	YES
Number of Pins	28
Weight	117.508773mg
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	28
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Applications	Pre-Amplifier, Professional Audio
Additional Feature	ALSO REQUIRES 2.7V TO 5.5V SUPPLY
Voltage - Supply	4.5V~5.5V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Terminal Pitch	0.65mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	DIT4096
Function	Line Driver
Qualification Status	Not Qualified
Operating Supply Voltage	5V
Power Supplies	5V
Number of Channels	1
Interface	SPI
Operating Supply Current	22mA
Nominal Supply Current	22mA
Output Power	150mW
Specifications	Differential Output
Consumer IC Type	CONSUMER CIRCUIT
Height	1.2mm
Length	9.7mm
Width	4.4mm
Thickness	1mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
Mfr	Texas Instruments
Series	-
Product Status	Active
Voltage - Supply	4.5V ~ 5.5V
Operating Temperature	-40°C ~ 85°C (TA)
Package / Case	28-TSSOP (0.173", 4.40mm Width)
Supplier Device Package	28-TSSOP
