DS1556WP-120IND Overviewreal time clocks is located in package 34-PowerCap™ Module.There is 2.97V ~ 3.63V voltage supply for this electrical RTC.It can be said that this electrical real time clock belongs to the Clock/Calendar type.The real time clock (RTC) that is mounted in the way of Surface Mount is connected to this circuit board.In order to operate properly, the temperature should be -40°C ~ 85°C.As far as the supply voltage for this electrical digital time clock is concerned, it is 3V.Clock & Timer ICs includes this component in its content.For the purpose of storing data and programs, the RTC times are embedded with a storage capacity of 128KB.It is a real-time clock in the series -.
DS1556WP-120IND Features34-PowerCap™ Module package
- series
DS1556WP-120IND ApplicationsThere are a lot of Analog Devices
DS1556WP-120IND Real Time Clocks applications.
Copy machines
Mobile equipment
Battery powered devices
Printers and copiers
Electronic metering
Digital cameras
White goods
Elapsed time counter
Network powered devices
Battery backed up systems
Mounting Type | Surface Mount |
Package / Case | 34-PowerCap™ Module |
Supplier Device Package | 34-PowerCap Module |
Mounting Style | SMD/SMT |
Package | Tube |
Base Product Number | DS1556 |
Mfr | Analog Devices Inc./Maxim Integrated |
Product Status | Obsolete |
Maximum Operating Temperature | + 85 C |
Supply Voltage - Max | 3.63 V |
Minimum Operating Temperature | - 40 C |
Supply Voltage - Min | 2.97 V |
RTC Bus Interface | Parallel |
RTC Memory Size | 128 kB |
Battery Backup Switching | Backup Switching |
Operating Temperature | -40°C ~ 85°C |
Series | - |
Type | Clock/Calendar |
Subcategory | Clock & Timer ICs |
Voltage - Supply | 2.97V ~ 3.63V |
Function | Calendar, Clock, NV Timekeeping RAM, Watchdog Timekeeper |
Interface | Parallel |
Memory Size | 128KB |
Product Type | Real Time Clocks |
Time Format | HH:MM:SS (24 hr) |
Date Format | YY-MM-DD-dd |
Current - Timekeeping (Max) | 4mA @ 3.3V |
Voltage - Supply, Battery | 3V |
Features | Alarm, Leap Year, NVSRAM, Watchdog Timer, Y2K |
Lead Free | Contains Lead |
