E-TDA7404D Overview
With the book, you will also receive a case study. In terms of mounting type, the recommended type is Surface Mount. In this case, it is embedded in the 28-SOIC (0.295, 7.50mm Width) case. This device has a 2 channel configuration. To assist you, this part includes Audio Signal Processor functions. It is possible to apply the device in the Automotive Audio axis. Votage will be supplied within the period of 7.5V~10.5V. In terms of temperature, this device works within a range of -40°C~85°C TA. The chip has 28 terminations. If you search for the TDA7404 family of parts, you will be able to find similar parts. On the chip, there are 28 pins that can be accessed. Sorting by TONE CONTROL CIRCUIT can be done based on what type of consumer IC the part contains. Vsup (supply voltage) should not be less than 7.5V when using this part. It can produce voltage at a voltage level of 9V volts. In this case, Vsup reaches its maximal value at 10.5V. Surface Mount is the one who mounts it. This item has 2 bands.
E-TDA7404D Features
With 28-SOIC (0.295, 7.50mm Width) channels
operate temperature at the range of -40°C~85°C TA
consumer IC type: TONE CONTROL CIRCUIT

E-TDA7404D Applications
There are a lot of STMicroelectronics
E-TDA7404D Audio Special Purpose applications.

Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
Distribution Amplifiers
Graphic and P arametric Equalizers
Dynamic Range Processors
Digital Effects Processors

Factory Lead Time	13 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	28-SOIC (0.295, 7.50mm Width)
Number of Pins	28
Operating Temperature	-40°C~85°C TA
Packaging	Tube
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	28
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Applications	Automotive Audio
Voltage - Supply	7.5V~10.5V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	250
Base Part Number	TDA7404
Function	Audio Signal Processor
Supply Voltage-Max (Vsup)	10.5V
Power Supplies	9V
Supply Voltage-Min (Vsup)	7.5V
Number of Channels	2
Interface	I2C
Consumer IC Type	TONE CONTROL CIRCUIT
Number of Bands	2
Harmonic Distortion	0.05%
Channel Separation	100 dB
Length	17.9mm
Width	7.5mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Mfr	STMicroelectronics
Series	-
Product Status	Active
Applications	Audio
Interface	I²C
Voltage - Supply	7.5V ~ 10.5V
Operating Temperature	-40°C ~ 85°C (TA)
Specifications	-
Grade	Automotive
Package / Case	28-SOIC (0.295", 7.50mm Width)
Supplier Device Package	28-SO
