FS-352 Overview
A MPU Core module or board is used in the microcontroller.It has ARM7TDMI, NS7520 cores and is driven by a processor.Microcontrollers are configured by default to 0°C~70°C.MCU chips flash size is 8MB.48-DIP' stands for connector type.A minimum RAM size of 16MB is set to enable the software to run normally.During operation, the MCU chip moves at 55MHz speed.55MHz frequency can still be used accurately.Microprocessor has the DIP package.70°C is the maximum operational temperature at this time.As microprocessor operates, microprocessor should be warmer than 0°C.A ARM architecture underpins micro controller's core.Powered by 3.3V volts, this microcontrollers operates on DC DC power.A value of FLASH, RAM has been selected for data storage.A memory of 16MB is embedded in the microchips, and this memory can be used to store data and programs.
FS-352 Features
Core processor of ARM7TDMI, NS7520
Flash size of 8MB
Speed of 55MHz
Core architecture of ARM

FS-352 Applications
There are a lot of Digi
FS-352 Microcontroller, Microprocessor, FPGA Modules applications.

Test and Measurement
Medical Devices
Data Acquisition
Industrial Control
Process Control
Process Monitoring
Healthcare Monitoring
Patient Monitoring
IoT Secure Gateways
Human Machine Interface

Mount	Through Hole
Package / Case	DIP
Number of Pins	48
Operating Temperature	0°C~70°C
Published	2012
Size / Dimension	2.48 x 0.73 62.9mmx18.5mm
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Connector Type	48-DIP
Max Operating Temperature	70°C
Min Operating Temperature	0°C
Frequency	55MHz
Operating Supply Voltage	3.3V
Interface	Ethernet, GPIO, I2C, SPI, UART
Memory Size	16MB
Speed	55MHz
RAM Size	16MB
Memory Type	FLASH, RAM
Core Processor	ARM7TDMI, NS7520
Data Rate	100 kbps
Core Architecture	ARM
Module/Board Type	MPU Core
Flash Size	8MB
Height	10.4mm
Length	62.9mm
Width	18.5mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
Lead Free	Contains Lead
