FSUSB22BQX OverviewTemperatures can be controlled at {0} according to the setting.
FSUSB22BQX FeaturesFSUSB22BQX ApplicationsThere are a lot of Rochester Electronics, LLC
FSUSB22BQX Special Purpose Analog Switches applications.
Filling
Food & beverage
Linear measurement
Material handling
Metal forming & fabrication
Mobile equipement
Motor feedback
Packaging
Printing
Registration mark timing
| Mounting Type | Surface Mount |
| Package / Case | 16-WFQFN Exposed Pad |
| Surface Mount | YES |
| Operating Temperature | -40°C~85°C TA |
| Packaging | Tape & Reel (TR) |
| JESD-609 Code | e4 |
| Feature | Bi-Directional, USB 2.0 |
| Pbfree Code | yes |
| Part Status | Obsolete |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Number of Terminations | 16 |
| Terminal Finish | NICKEL PALLADIUM GOLD |
| Applications | USB |
| Terminal Position | QUAD |
| Terminal Form | NO LEAD |
| Peak Reflow Temperature (Cel) | 260 |
| Number of Functions | 2 |
| Supply Voltage | 3.3V |
| Terminal Pitch | 0.5mm |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Pin Count | 16 |
| JESD-30 Code | R-XQCC-N16 |
| Supply Voltage-Max (Vsup) | 3.6V |
| Number of Channels | 4 |
| Analog IC - Other Type | DPDT |
| -3db Bandwidth | 750MHz |
| On-State Resistance (Max) | 6.5Ohm |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Off-state Isolation-Nom | 30 dB |
| On-state Resistance Match-Nom | 0.3Ohm |
| Switch Circuit | SPDT |
| Switch-on Time-Max | 6ns |
| Voltage - Supply, Single (V+) | 3V~3.6V |
| Length | 3.5mm |
| Height Seated (Max) | 0.8mm |
| RoHS Status | ROHS3 Compliant |
| Supplier Device Package | 16-DQFN (2.5x3.5) |
| Package | Bulk |
| Mfr | Fairchild Semiconductor |
| Product Status | Obsolete |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Series | - |
| Voltage - Supply, Single (V+) | 3V ~ 3.6V |
| Voltage - Supply, Dual (V±) | - |
| Features | Bi-Directional, USB 2.0 |
