LM324, LM224, LM2902, NCV2902, Single Supply, Quad Operational Amplifiers, ON SemiconductorThe ON Semiconductor LM324/LM224/LM2902/NCV2902 quad operational amplifiers with true differential inputs can operate at supply voltages between 3 V and 32 V. The common mode input range includes the negative supply eliminating the need for external biasing components in many applications. The output voltage range also includes the negative power supply voltage.

Alternate Mfr Part Number	6896703
Amplifier Type	Quad Operational
Channel Separation	-120 dB
Common Mode Rejection Ratio	70 dB
Dimensions	0.059\” (1.5mm) X 0.00 in W X 0.34 in L
Dimensions	8.75 x 4.00 x 1.50 mm
Gain Bandwidth	1 MHz
Height	0.059" (1.5mm)
Input Bias Current	Maximum of -250 nA
Input Offset Current	Maximum of 200 nA
Input Offset Voltage	10 mV
Input Voltage	-0.3 to 32
Input Voltage Range	0 to 28.3 V
Length	0.344 in
Maximum Operating Temperature	+105 °C
Minimum Operating Temperature	-40 °C
Mounting Type	Surface Mount
Number of Amplifiers	Quad
Number of Channels per Chip	4
Number of Pins	14
Output Current	60 mA
Output Type	Swing
Package Type	SOIC
Product Header	Single Supply Quad Operational Amplifier
Series	LM Amplifier Series
Slew Rate	0.6 V/μs
Supply Current	3 mA
Temperature Operating Range	-40 to +105 °C
Type of Power Supply	Single Output
Typical Single Supply Voltage	3 to 32 V
Voltage, Input, High Level	28.3 V
Voltage, Input, Low Level	0 V
Voltage, Output, High Level	3.5 V
Voltage, Output, Low Level	5 mV
Width	0 in
