Operational Amplifiers include single, dual or quad amplifiers in space-saving packages. These devices operate down to 1.8 V and feature rail-to-rail inputs and outputs for improved system performance and low current consumption for extended battery life (600 nA for MCP604X and 614X families). These products offer low offset (VOS 150 μV), low bias current, high speed operation (10 MHz), high open-loop gain and other options for the embedded system designer.

Amplifier Type	General Purpose
Common Mode Rejection Ratio	76 dB
Density Noise	28 nV/vHz
Dimensions	0.051\” (1.3mm) X 0.00 in W X 0.12 in L
Dimensions	3.10 x 1.80 x 1.30 mm
Gain Bandwidth	1 MHz
Height	0.051" (1.3mm)
Input Bias Current	19 pA
Input Offset Current	±1 pA
Input Offset Voltage	4.5 mV
Input Voltage	1.5 to 2.1
Input Voltage Range	-0.3 to 5.8 V
Length	0.12 in
Maximum Operating Temperature	+85 °C
Minimum Operating Temperature	-40 °C
Mounting Type	Surface Mount
Noise Voltage	28 nV/sqrt Hz
Number of Amplifiers	Single
Number of Channels per Chip	1
Number of Pins	5
Output Current	23 mA
Output Type	Rail to Rail
Package Type	PSOT
Product Header	Low-Power Operational Amplifier
Slew Rate	0.6 V/μs
Supply Current	+/-30 mA
Temperature Operating Range	-40 to +85 °C
Type of Power Supply	Single Output
Typical Single Supply Voltage	1.8 to 6 V
Voltage, Input, High Level	5.8 V
Voltage, Input, Low Level	-0.3 V
Voltage, Output, High Level	1775 mV
Voltage, Output, Low Level	1775 mV
Width	0 in
