Operational Amplifiers include single, dual or quad amplifiers in space-saving packages. These devices operate down to 1.8 V and feature rail-to-rail inputs and outputs for improved system performance and low current consumption for extended battery life (600 nA for MCP604X and 614X families). These products offer low offset (VOS 150 μV), low bias current, high speed operation (10 MHz), high open-loop gain and other options for the embedded system designer.

Amplifier Type	Precision
Common Mode Rejection Ratio	95 dB
Density Noise	165 nV/vHz
Dimensions	0.051\” (1.3mm) X 0.00 in W X 0.12 in L
Dimensions	3.10 x 1.80 x 1.30 mm
Gain Bandwidth	10 kHz
Height	0.051" (1.3mm)
Input Bias Current	5000 pA
Input Offset Current	+/-1 pA
Input Offset Voltage	+/-150 μV
Input Voltage	1.5 to 2.1
Input Voltage Range	-0.3 to 5.8 V
Length	0.12 in
Maximum Operating Temperature	+125 °C
Minimum Operating Temperature	-40 °C
Mounting Type	Surface Mount
Noise Voltage	165 nV/sqrt Hz
Number of Amplifiers	Single
Number of Channels per Chip	1
Number of Circuits	1
Number of Pins	5
Output Current	23 mA
Output Type	Rail to Rail
Package Type	PSOT
Product Header	High Precision Operation Amplifier
Slew Rate	4 V/ms
Supply Current	±30 mA
Temperature Operating Range	-40 to +125 °C
Type of Power Supply	Single Output
Typical Single Supply Voltage	1.8 to 5.5 V
Voltage, Input, High Level	5.8 V
Voltage, Input, Low Level	-0.3 V
Voltage, Output, High Level	1790 mV
Voltage, Output, Low Level	1790 mV
Width	0 in
