TDA7419 Overview
With Tube, it comes in a case. A Surface Mount mounting type is recommended for this product. In 28-SOIC (0.295, 7.50mm Width) case, it is embedded. With 4 channels, the device is equipped. You can refer to Audio Signal Processor functions in this part. Automotive Audio is one of the possible applications of the device. Votage within 8V~10V is supplied. The device operates at a temperature in the range -40°C~85°C TA. On the chip, there are 28 terminations. Using the TDA7419 family as a search term will yield similar parts. On the chip, 28 pins are accessible. Consumer IC types can be sorted with TONE CONTROL CIRCUIT. This part should have a minimum supply voltage of 8V (Vsup). Once 10V is reached, the maximal supply voltage (Vsup) is reached. Automotive, AEC-Q100-series components are used in this electrical component. In a 8.5V-volt supply voltage, the chip conducts. On it are 3 bands. 15 dB should remain the voltage gain.
TDA7419 Features
With 28-SOIC (0.295, 7.50mm Width) channels
operate temperature at the range of -40°C~85°C TA
consumer IC type: TONE CONTROL CIRCUIT

TDA7419 Applications
There are a lot of STMicroelectronics
TDA7419 Audio Special Purpose applications.

Consumer electronics
AV/DVD Receiver, AV Amplifier
Car or Mobile Audio System
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers

Lifecycle Status	ACTIVE (Last Updated: 8 months ago)
Factory Lead Time	11 Weeks
Mounting Type	Surface Mount
Package / Case	28-SOIC (0.295, 7.50mm Width)
Surface Mount	YES
Number of Pins	28
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	Automotive, AEC-Q100
JESD-609 Code	e4
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	28
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Applications	Automotive Audio
Voltage - Supply	8V~10V
Terminal Position	DUAL
Terminal Form	GULL WING
Terminal Pitch	1.27mm
Base Part Number	TDA7419
Function	Audio Signal Processor
Operating Supply Voltage	8.5V
Supply Voltage-Max (Vsup)	10V
Supply Voltage-Min (Vsup)	8V
Number of Channels	4
Interface	I2C
Nominal Supply Current	35mA
Common Mode Rejection Ratio	45 dB
Input Offset Voltage (Vos)	500μV
Gain	15 dB
Consumer IC Type	TONE CONTROL CIRCUIT
Number of Bands	3
Channel Separation	90 dB
Length	17.9mm
Height Seated (Max)	2.65mm
Width	7.5mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
Mfr	STMicroelectronics
Series	-
Product Status	Last Time Buy
Applications	Audio
Interface	I²C
Voltage - Supply	8V ~ 10V
Operating Temperature	-40°C ~ 85°C (TA)
Specifications	-
Grade	Automotive
Qualification	AEC-Q100
Package / Case	28-SOIC (0.295", 7.50mm Width)
Supplier Device Package	28-SO
