TDA7476 OverviewThere is also an accompanying case included with this set. There is a recommendation that it should be mounted with a Surface Mount type mount. The file is embedded in a 24-SOIC (0.295, 7.50mm Width) case. This device has 5 channels. For your reference, here are some Audio Signal Processor functions. It can be used in Automotive Audio. There is a supply of votage within 18V. A chip has 24 terminations. You can find similar parts by searching for the TDA7476 family. Chips have 24 pins that can be accessed. It is possible to sort parts based on their consumer IC type using CONSUMER CIRCUIT. It should not be possible to power this part with a voltage lower than 14.4V (Vsup). Voltage can be generated at 14V volts with this device. A maximum supply voltage (Vsup) is reached at 14.4V. Using it below 85°C is recommended. Chips are operated at -40°C operating temperatures or higher.
TDA7476 FeaturesWith 24-SOIC (0.295, 7.50mm Width) channels
consumer IC type: CONSUMER CIRCUIT
TDA7476 ApplicationsThere are a lot of STMicroelectronics
TDA7476 Audio Special Purpose applications.
AV/DVD Receiver, AV Amplifier
Car or Mobile Audio System
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
| Mounting Type | Surface Mount |
| Package / Case | 24-SOIC (0.295, 7.50mm Width) |
| Surface Mount | YES |
| Number of Pins | 24 |
| Packaging | Bulk |
| JESD-609 Code | e4 |
| Pbfree Code | no |
| Part Status | Obsolete |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Number of Terminations | 24 |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Applications | Automotive Audio |
| Voltage - Supply | 18V |
| Terminal Position | DUAL |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27mm |
| Base Part Number | TDA7476 |
| Function | Audio Signal Processor |
| Supply Voltage-Max (Vsup) | 14.4V |
| Power Supplies | 14V |
| Supply Voltage-Min (Vsup) | 14.4V |
| Number of Channels | 5 |
| Interface | I2C |
| Output Power | 1.5W |
| Consumer IC Type | CONSUMER CIRCUIT |
| Radiation Hardening | No |
| RoHS Status | ROHS3 Compliant |
| Mfr | STMicroelectronics |
| Series | - |
| Product Status | Obsolete |
| Applications | Audio |
| Interface | I²C |
| Operating Temperature | - |
| Specifications | - |
| Grade | Automotive |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 24-SO |
