| Manufacturer | Texas Instruments |
| Product Category | AC DC Converters, Offline Switchers |
| Series | UCC28880 |
| Product | AC/DC Converters |
| Type | Lowest Quiescent Current Off-Line Switcher |
| Packaging | Tube Alternate Packaging |
| Unit-Weight | 0.008960 oz |
| Mounting-Style | SMD/SMT |
| Operating-Temperature-Range | - 40 C to + 105 C |
| Package-Case | 8-SOIC (0.154", 3.90mm Width) 7 leads |
| Operating-Temperature | -40°C ~ 105°C (TA) |
| Mounting-Type | Surface Mount |
| Supplier-Device-Package | 7-SOIC |
| Watt | - |
| Number-of-Outputs | 1 Output |
| Output-Isolation | Non-Isolated |
| Internal-Switch-s | Yes |
| Voltage-Breakdown | 700V |
| Topology | Buck, Buck-Boost, Flyback |
| Voltage-Start-Up | 3.9V |
| Voltage-Supply-Vcc-Vdd | 3.6 V ~ 5 V |
| Duty-Cycle | 55% |
| Frequency-Switching | 62kHz |
| Fault-Protection | Current Limiting, Over Load, Over Temperature, Short Circuit |
| Control-Features | - |
| Isolation | Non-Isolated |
| Output-Voltage | 3.3 V |
| Operating-Supply-Current | 72 uA |
| Output-Current | 100 mA |
| Switching-Frequency | 62 kHz |
| Package-Case | SOIC-7 |
| Duty-Cycle-Max | 55 % |
| Input-Supply-Voltage-Min | 30 V |
| Input-Supply-Voltage-Max | 700 V |
UCC28880D Datasheet
