74LVTH16501MTD Overview
56-TFSOP (0.240, 6.10mm Width) contains this file. Tube is how it's packaged. Flexible 18-Bit circuits are used to achieve its superior performance. A Universal Bus Transceiver logic type is used in this electrical device. In this case, the electronic part is mounted in the direction of Surface Mount. Over -40°C~85°C, the operating temperature should be higher. High/Low output currents allow 32mA 64mA to have a maximum design flexibility. As part of the 74LVTH series, it is a type of FPGA. Powered by 2.7V~3.6V, it operates on a voltage of V. The 56 termination is a practice in which a transmission line is terminated with an impedance matching device at the end of the line in order to match the characteristic impedance of the line. Normal operation requires an output voltage above 3.3V. 56 pins are present in the device. It is designed with 18 Bits. It is possible to terminate a transmission line with a device that matches the line's characteristic impedance, known as 2 terminations. In the family of LVT devices, this electronic device belongs. It reaches 3.6V when the maximum supply voltage (Vsup) is reached. There should be a greater supply voltage (Vsup) than 2.7V.
74LVTH16501MTD Features
56-TFSOP (0.240, 6.10mm Width) package
74LVTH series
56 pin count

74LVTH16501MTD Applications
There are a lot of Rochester Electronics, LLC
74LVTH16501MTD Universal Bus Functions applications.

Industrial Controls
Telecommunications
Instrumentation Systems
Air conditioner
Home theater
Electric grinding wheel
Electrical tools
Sewing machine
DVD
VCD

Mounting Type	Surface Mount
Package / Case	56-TFSOP (0.240, 6.10mm Width)
Surface Mount	YES
Operating Temperature	-40°C~85°C
Packaging	Tube
Series	74LVTH
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	56
Terminal Finish	MATTE TIN
Voltage - Supply	2.7V~3.6V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Supply Voltage	3.3V
Terminal Pitch	0.5mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	56
JESD-30 Code	R-PDSO-G56
Qualification Status	COMMERCIAL
Supply Voltage-Max (Vsup)	3.6V
Supply Voltage-Min (Vsup)	2.7V
Number of Circuits	18-Bit
Number of Ports	2
Number of Bits	18
Family	LVT
Output Characteristics	3-STATE
Current - Output High, Low	32mA 64mA
Logic Type	Universal Bus Transceiver
Output Polarity	TRUE
Propagation Delay (tpd)	6.2 ns
Length	14mm
Height Seated (Max)	1.2mm
Width	6.1mm
RoHS Status	ROHS3 Compliant
Supplier Device Package	56-TSSOP
Package	Tube
Base Product Number	74LVTH16501
Mfr	Fairchild Semiconductor
Product Status	Obsolete
Operating Temperature	-40°C ~ 85°C
Voltage - Supply	2.7V ~ 3.6V
Current - Output High, Low	32mA, 64mA
