| Lifecycle Status | ACTIVE (Last Updated: 6 days ago) |
| Factory Lead Time | 6 Weeks |
| Contact Plating | Gold |
| Mount | Surface Mount |
| Mounting Type | Surface Mount |
| Package / Case | 56-TFSOP (0.240, 6.10mm Width) Exposed Pad |
| Number of Pins | 56 |
| Operating Temperature | 0°C~85°C TA |
| Packaging | Tape & Reel (TR) |
| JESD-609 Code | e4 |
| Pbfree Code | yes |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Number of Terminations | 56 |
| ECCN Code | EAR99 |
| Applications | Digital Audio Interfacing |
| Voltage - Supply | 3V~3.6V |
| Terminal Position | DUAL |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Terminal Pitch | 0.5mm |
| Base Part Number | TAS5558 |
| Function | Modulator |
| Operating Supply Voltage | 3.3V |
| Supply Voltage-Max (Vsup) | 3.6V |
| Supply Voltage-Min (Vsup) | 3V |
| Number of Channels | 8 |
| Interface | I2C, I2S |
| Nominal Supply Current | 220mA |
| Resolution | 7.5 B |
| Specifications | 32kHz ~ 192kHz |
| Consumer IC Type | CONSUMER CIRCUIT |
| Signal to Noise Ratio (SNR) | 105 dB |
| Height | 1.2mm |
| Length | 14mm |
| Width | 6.1mm |
| Thickness | 1.15mm |
| Radiation Hardening | No |
| RoHS Status | ROHS3 Compliant |
| Lead Free | Lead Free |
| Mfr | Texas Instruments |
| Series | - |
| Product Status | Active |
| Interface | I²C, I²S |
| Voltage - Supply | 3V ~ 3.6V |
| Operating Temperature | 0°C ~ 85°C (TA) |
| Package / Case | 56-PowerTFSOP (0.240", 6.10mm Width) |
| Supplier Device Package | 56-HTSSOP |
TAS5558DCAR Datasheet
