| Lifecycle Status | ACTIVE (Last Updated: 5 days ago) |
| Factory Lead Time | 6 Weeks |
| Mounting Type | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad |
| Surface Mount | YES |
| Number of Pins | 16 |
| Weight | 50.008559mg |
| Operating Temperature | -40°C~85°C TA |
| Packaging | Tape & Reel (TR) |
| JESD-609 Code | e4 |
| Pbfree Code | yes |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| Number of Terminations | 16 |
| ECCN Code | EAR99 |
| Resistance | 30Ohm |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Applications | Consumer Audio |
| Voltage - Supply | 2.5V~4.5V |
| Terminal Position | QUAD |
| Terminal Form | NO LEAD |
| Terminal Pitch | 0.5mm |
| Base Part Number | TS3A227 |
| Output | SEPARATE OUTPUT |
| Function | Detection Switch |
| Operating Supply Voltage | 3.3V |
| Number of Channels | 1 |
| Interface | I2C |
| Analog IC - Other Type | AUDIO/VIDEO SWITCH |
| Max Supply Current | 45μA |
| Turn On Delay Time | 35 μs |
| Input Voltage (Min) | 2.5V |
| Input Voltage (Max) | 4.5V |
| Bandwidth | 150MHz |
| Turn-Off Delay Time | 500 μs |
| Off-state Isolation-Nom | -90 dB |
| Switching | BREAK-BEFORE-MAKE |
| Switch-on Time-Max | 35000ns |
| Switch-off Time-Max | 5000ns |
| Height | 1mm |
| Length | 3.5mm |
| Width | 3.5mm |
| Thickness | 900μm |
| REACH SVHC | No SVHC |
| RoHS Status | ROHS3 Compliant |
| Lead Free | Lead Free |
| Mfr | Texas Instruments |
| Series | - |
| Product Status | Active |
| Interface | I²C |
| Voltage - Supply | 2.5V ~ 4.5V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Specifications | - |
| Supplier Device Package | 16-VQFN (3.5x3.5) |
TS3A227ERVAR Datasheet
