DS1040Z-75+ Overview
Using the 8-SOIC (0.154, 3.90mm Width) package eliminates the need to install additional insulating hardware in the application. The supply voltage of 4.75V ~ 5.25V ensures reliable performance. In order to mount this device, the technique of Surface Mount is used. The device is capable of operating at a temperature of 0°C ~ 70°C. As a result, it is configured with 5 taps/steps. The package number of its supplier is 8-SOIC. It is part of the - series of electronic devices that are among the most significant.
DS1040Z-75+ Features
Mounting Type: -

DS1040Z-75+ Applications
There are a lot of Analog Devices
DS1040Z-75+ Delay Lines Timing ICs applications.

Digital Systems
Embedded Systems
Utility Meters
Security Systems
Network Hubs, Bridges, and Routers
QDR/QDRII Memory Systems
Multiphase Clock Generation
LCD Televisions
Telecommunications
Digital Test Equipment

Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154, 3.90mm Width)
Supplier Device Package	8-SOIC
Package	Tube
Base Product Number	DS1040
Mfr	Analog Devices Inc./Maxim Integrated
Product Status	Obsolete
Operating Temperature	0°C ~ 70°C
Series	-
Voltage - Supply	4.75V ~ 5.25V
Function	1-Shot, Programmable
Number of Taps/Steps	5
Number of Independent Delays	1
Delay to 1st Tap	15ns
Available Total Delays	75ns
Tap Increment	15 ns
