DS1100M-300 Overview
With the 8-DIP (0.300, 7.62mm) package, additional insulating hardware in applications is no longer necessary. Providing reliable performance is made possible by the supply voltage of 4.75V ~ 5.25V. As a mounting method, the technique Through Hole is used. In addition, it is equipped with -40°C ~ 85°C operating temperature. There are 5 taps and steps configured for it. This device's supplier package is 8-PDIP. There are several important electronic devices that belong to the - series.
DS1100M-300 Features
Mounting Type: -

DS1100M-300 Applications
There are a lot of Analog Devices
DS1100M-300 Delay Lines Timing ICs applications.

Clock Synchronization
Digital Systems
Embedded Systems
Utility Meters
Security Systems
Network Hubs, Bridges, and Routers
QDR/QDRII Memory Systems
Multiphase Clock Generation
LCD Televisions
Telecommunications

Mounting Type	Through Hole
Package / Case	8-DIP (0.300, 7.62mm)
Supplier Device Package	8-PDIP
Package	Tube
Base Product Number	DS1100
Mfr	Analog Devices Inc./Maxim Integrated
Product Status	Obsolete
Operating Temperature	-40°C ~ 85°C
Series	-
Voltage - Supply	4.75V ~ 5.25V
Function	Nonprogrammable
Number of Taps/Steps	5
Number of Independent Delays	1
Delay to 1st Tap	60ns
Available Total Delays	300ns
Tap Increment	60 ns
