MAX4555CSE+ Overview
It is for your convenience that this part includes {0} functions.
MAX4555CSE+ Features

MAX4555CSE+ Applications
There are a lot of Maxim Integrated
MAX4555CSE+ Special Purpose Analog Switches applications.

Filling
Food & beverage
Linear measurement
Material handling
Metal forming & fabrication
Mobile equipement
Motor feedback
Packaging
Printing
Registration mark timing

Factory Lead Time	10 Weeks
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.154, 3.90mm Width)
Surface Mount	YES
Operating Temperature	0°C~70°C TA
Packaging	Tube
Published	1998
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	16
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Applications	Force Sense
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	4
Supply Voltage	15V
Terminal Pitch	1.27mm
Time@Peak Reflow Temperature-Max (s)	30
Base Part Number	MAX4555
Output	SEPARATE OUTPUT
Pin Count	16
JESD-30 Code	R-PDSO-G16
Qualification Status	Not Qualified
Power Supplies	5+-15V
Number of Channels	4
Voltage - Supply, Single/Dual (±)	9V~40V ±4.5V~20V
Neg Supply Voltage-Nom (Vsup)	-15V
On-State Resistance (Max)	6Ohm
Multiplexer/Demultiplexer Circuit	1:1
Off-state Isolation-Nom	38 dB
On-state Resistance Match-Nom	0.3Ohm
Switch Circuit	SPST
Switch-on Time-Max	325ns
Switch-off Time-Max	325ns
Normal Position	NO
Length	9.9mm
Height Seated (Max)	1.75mm
Width	3.9mm
RoHS Status	ROHS3 Compliant
Lifecycle Status	Production (Last Updated: 1 month ago)
Mount	Surface Mount
Number of Pins	16
Supplier Device Package	16-SOIC
Mounting Style	SMD/SMT
Manufacturer Lifecycle Status	PRODUCTION (Last Updated: 1 month ago)
RoHS	Compliant
Turn-On Delay Time	275 ns
Package	Tube
Base Product Number	MAX4555
Mfr	Analog Devices Inc./Maxim Integrated
Product Status	Obsolete
Maximum Operating Temperature	+ 70 C
Supply Voltage - Max	40 V
Minimum Dual Supply Voltage	+/- 4.5 V
Minimum Operating Temperature	0 C
Supply Voltage - Min	9 V
On Resistance - Max	30 Ohms
Off Time - Max	275 ns
On Time - Max	275 ns
Maximum Dual Supply Voltage	+/- 20 V
Packaging	Bulk
Operating Temperature	0°C ~ 70°C (TA)
Series	-
Resistance	6 Ω
Max Operating Temperature	70 °C
Min Operating Temperature	0 °C
Max Power Dissipation	696 mW
Configuration	4 x SPST
Number of Channels	6
Max Supply Voltage	20 V
Min Supply Voltage	4.5 V
Nominal Supply Current	1 nA
Max Supply Current	1 µA
Number of Bits	4
Throw Configuration	SPST
Supply Type	Dual, Single
Turn-Off Delay Time	275 ns
Max Dual Supply Voltage	20 V
-3db Bandwidth	-
Min Dual Supply Voltage	4.5 V
Voltage - Supply, Single (V+)	9V ~ 40V
Voltage - Supply, Dual (V±)	±4.5V ~ 20V
Features	-
Radiation Hardening	No
Lead Free	Contains Lead
