Critical Conduction GreenLinet SMPS Controller

The MC33364 series are variable frequency SMPS controllers that operate in the critical conduction mode. They are optimized for high density power supplies requiring minimum board area, reduced component count, and low power dissipation. Integration of the high voltage startup saves approximately 0.7 W of power compared to the value of the resistor bootstrapped circuits.

Features• Lossless Off--Line Startup
• Leading Edge Blanking for Noise Immunity
• Watchdog Timer to Initiate Switching
• Operating Temperature Range --25°C to +125°C
• Shutdown Capability
• Over Temperature Protection
• Optional/Adjustable Frequency Clamp to Limit EMI
• This is a Pb--Free and Halide--Free Device

Manufacturer	onsemi
Product Category	AC DC Converters, Offline Switchers
Series	GreenLine™
Packaging	Tube Alternate Packaging
Unit-Weight	0.023492 oz
Mounting-Style	SMD/SMT
Package-Case	16-SOIC (0.154", 3.90mm Width) 14 Leads
Operating-Temperature	-25°C ~ 125°C (TA)
Mounting-Type	Surface Mount
Supplier-Device-Package	16-SOIC
Watt	-
Number-of-Outputs	1 Output
Output-Isolation	Isolated
Internal-Switch-s	No
Voltage-Breakdown	700V
Topology	Flyback
Voltage-Start-Up	15V
Voltage-Supply-Vcc-Vdd	7.6 V ~ 16 V
Duty-Cycle	-
Frequency-Switching	126kHz
Fault-Protection	Current Limiting, Over Temperature
Control-Features	Frequency Control
Maximum Operating Temperature	+ 125 C
Operating temperature range	- 25 C
Operating-Supply-Voltage	16 V
Output-Voltage	4.90 V to 5.20 V
Output-Current	600 mA
Fall-Time	28 ns
Rise-Time	67 ns
Package-Case	SOIC-16
