SA572DR2G Overview
This item comes with a case that goes with it. The mounting type that is recommended is Surface Mount. The embedded file is in the 16-SOIC (0.295, 7.50mm Width) case. The device has a 2 channel. Here is a list of Compandor functions for your reference. There is the possibility of applying the device in Consumer Audio, Telecommunication Systems. There is a delivery within 6V~22V of the votage. In this device, temperature is measured in the -40°C~85°C TA range. On the chip, 16 terminations are present. If you search for the SA572 family, you will find similar parts. Here are the device specifications: 110dB. The chip contains 16 pins. It is recommended that the minimum supply voltage (Vsup) for this part be higher than 6V. At 15V volts, it can provide voltage. There is a voltage range of 15V that it can handle. The analog IC employed by this device is called COMPANDER.
SA572DR2G Features
With 16-SOIC (0.295, 7.50mm Width) channels
operate temperature at the range of -40°C~85°C TA
Supply voltage at 15V volts

SA572DR2G Applications
There are a lot of ON Semiconductor
SA572DR2G Audio Special Purpose applications.

Car or Mobile Audio System
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
Distribution Amplifiers

Lifecycle Status	ACTIVE (Last Updated: 1 week ago)
Factory Lead Time	2 Weeks
Contact Plating	Tin
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.295, 7.50mm Width)
Surface Mount	YES
Number of Pins	16
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Published	2005
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	16
ECCN Code	EAR99
Applications	Consumer Audio, Telecommunication Systems
Voltage - Supply	6V~22V
Terminal Position	DUAL
Terminal Form	GULL WING
Supply Voltage	15V
Base Part Number	SA572
Function	Compandor
Power Supplies	15V
Supply Voltage-Min (Vsup)	6V
Number of Channels	2
Interface	Analog
Analog IC - Other Type	COMPANDER
Halogen Free	Halogen Free
Supply Current-Max (Isup)	6.3mA
Specifications	110dB
Length	10.3mm
Width	7.5mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
Mfr	onsemi
Series	-
Product Status	Active
Voltage - Supply	6V ~ 22V
Operating Temperature	-40°C ~ 85°C (TA)
Package / Case	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package	16-SOIC
