SL811HST-AC Overview
Considering its outstanding performance, USB Host/Slave Controller is an excellent choice.Due to its space-saving qualities, it is available in the 48-LQFP package.Mounted using Surface Mount.You can find it in the package of Tray.Application Specific Microcontroller is important to keep the temperature at 0°C~65°C while working.By using a 3V~3.6V voltage supply, high efficiency is possible.A total of 8 I/Os are available on this device.To find comparable components, use the SL811 base part number.This device has terminals at QUAD.Application Specific Microcontroller is a member of the USB-Hosts controller series.In this case, there are 48 terminations.By using a 3.3V voltage supply, high efficiency is possible.Application Specific Microcontroller has uPs/uCs/Peripheral IC - BUS CONTROLLER, UNIVERSAL SERIAL BUS.A number of 48 pins are used to construct it.Mounting is performed in accordance with Surface Mount.Microcontroller is equipped wMicrocontrollerh 48 pins in total.Supply current is maximum at 25mA.Power is provided by a 3.3V source.Using a frequency of 48MHz, it is very efficient.
SL811HST-AC Features
48-LQFP package
Mounting type of Surface Mount

SL811HST-AC Applications
There are a lot of Cypress Semiconductor Corp
SL811HST-AC Microcontroller applications.

Robots
Radio
Television
Heater/Fan
Calculator
Kindle
Christmas lights
3D printers
Washing machine
Microwave ovens

Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	48-LQFP
Number of Pins	48
Operating Temperature	0°C~65°C
Packaging	Tray
Published	2002
JESD-609 Code	e0
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	48
ECCN Code	3A001.A.3
Terminal Finish	Tin/Lead (Sn/Pb)
Applications	USB Host/Slave Controller
Voltage - Supply	3V~3.6V
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	240
Supply Voltage	3.3V
Terminal Pitch	0.5mm
Frequency	48MHz
Time@Peak Reflow Temperature-Max (s)	30
Base Part Number	SL811
Pin Count	48
Power Supplies	3.3V
Interface	USB
Number of I/O	8
RAM Size	256 x 8
uPs/uCs/Peripheral ICs Type	BUS CONTROLLER, UNIVERSAL SERIAL BUS
Supply Current-Max	25mA
Address Bus Width	8
External Data Bus Width	8
Bus Compatibility	ISA; PCMCIA
Controller Series	USB-Hosts
Length	7mm
Height Seated (Max)	1.7mm
Width	7mm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead
Supplier Device Package	48-TQFP (7x7)
Package	Bag
Base Product Number	SL811
Mfr	Infineon Technologies
Product Status	Obsolete
Operating Temperature	0°C ~ 65°C
Series	-
Voltage - Supply	3V ~ 3.6V
Core Processor	-
Program Memory Type	-
