TAS5504APAG OverviewThere is also an accompanying case included with this set. There is a recommendation that it should be mounted with a Surface Mount type mount. The file is embedded in a 64-TQFP case. This device has 4 channels. For your reference, here are some Modulator functions. It can be used in Digital Audio Interfacing. There is a supply of votage within 3.3V. A chip has 64 terminations. You can find similar parts by searching for the TAS5504 family. Chips have 64 pins that can be accessed. It is possible to sort parts based on their consumer IC type using CONSUMER CIRCUIT. It should not be possible to power this part with a voltage lower than 3V (Vsup). Voltage can be generated at 3.3V volts with this device. In this case, Surface Mount mounts it. 3.6V is the supply voltage for the chip. Using it below 70°C is recommended. Chips are operated at 0°C operating temperatures or higher.
TAS5504APAG FeaturesWith 64-TQFP channels
consumer IC type: CONSUMER CIRCUIT
TAS5504APAG ApplicationsThere are a lot of Texas Instruments
TAS5504APAG Audio Special Purpose applications.
AV/DVD Receiver, AV Amplifier
Car or Mobile Audio System
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
| Mount | Surface Mount |
| Mounting Type | Surface Mount |
| Package / Case | 64-TQFP |
| Number of Pins | 64 |
| Weight | 270.000858mg |
| Packaging | Tray |
| JESD-609 Code | e4 |
| Part Status | Not For New Designs |
| Moisture Sensitivity Level (MSL) | 4 (72 Hours) |
| Number of Terminations | 64 |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Applications | Digital Audio Interfacing |
| Voltage - Supply | 3.3V |
| Terminal Position | QUAD |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Terminal Pitch | 0.5mm |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Base Part Number | TAS5504 |
| Function | Modulator |
| Qualification Status | Not Qualified |
| Operating Supply Voltage | 3.6V |
| Power Supplies | 3.3V |
| Temperature Grade | COMMERCIAL |
| Supply Voltage-Min (Vsup) | 3V |
| Number of Channels | 4 |
| Interface | I2C, I2S |
| Output Power | 1.869W |
| Consumer IC Type | CONSUMER CIRCUIT |
| Length | 10mm |
| Height Seated (Max) | 1.2mm |
| Width | 10mm |
| RoHS Status | ROHS3 Compliant |
| Lead Free | Lead Free |
| Mfr | Texas Instruments |
| Series | - |
| Product Status | Not For New Designs |
| Interface | I²C, I²S |
| Operating Temperature | - |
| Specifications | - |
| Supplier Device Package | 64-TQFP (10x10) |
