TAS5504APAGR OverviewAdditionally, there is a case included with the book as well. The mounting type recommended by the manufacturer is Surface Mount. A 64-TQFP case contains it. A 4 channel is present on the device. For your reference, this part contains Modulator functions. Digital Audio Interfacing can be used with the device. We supply it within 3.3V. It has 64 terminations. A search for parts belonging to the TAS5504 family will yield similar results. An accessible 64 pin can be found on the chip. You can use CONSUMER CIRCUIT to sort consumer ICs on a part. In order to operate this part, the minimum supply voltage (Vsup) must not be less than 3V volts. A voltage of 3.3V volts can be given by it. The mount is made by Surface Mount. The chip conducts in a 3.6V-voltage supply. The method should be used when the temperature is below 70°C. During operation, the chip should not be operated below 0°C degrees Celsius.
TAS5504APAGR FeaturesWith 64-TQFP channels
consumer IC type: CONSUMER CIRCUIT
TAS5504APAGR ApplicationsThere are a lot of Texas Instruments
TAS5504APAGR Audio Special Purpose applications.
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
Audio Differential Line Drivers
Audio Mix Consoles
Distribution Amplifiers
Graphic and P arametric Equalizers
| Contact Plating | Gold |
| Mount | Surface Mount |
| Mounting Type | Surface Mount |
| Package / Case | 64-TQFP |
| Number of Pins | 64 |
| Weight | 270.000858mg |
| Packaging | Tape & Reel (TR) |
| JESD-609 Code | e4 |
| Part Status | Not For New Designs |
| Moisture Sensitivity Level (MSL) | 4 (72 Hours) |
| Number of Terminations | 64 |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Applications | Digital Audio Interfacing |
| Voltage - Supply | 3.3V |
| Terminal Position | QUAD |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Terminal Pitch | 0.5mm |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Base Part Number | TAS5504 |
| Function | Modulator |
| Qualification Status | Not Qualified |
| Operating Supply Voltage | 3.6V |
| Power Supplies | 3.3V |
| Temperature Grade | COMMERCIAL |
| Supply Voltage-Min (Vsup) | 3V |
| Number of Channels | 4 |
| Interface | I2C, I2S |
| Output Power | 1.869W |
| Consumer IC Type | CONSUMER CIRCUIT |
| Length | 10mm |
| Height Seated (Max) | 1.2mm |
| Width | 10mm |
| RoHS Status | ROHS3 Compliant |
| Lead Free | Lead Free |
| Mfr | Texas Instruments |
| Series | - |
| Product Status | Not For New Designs |
| Interface | I²C, I²S |
| Operating Temperature | - |
| Specifications | - |
| Supplier Device Package | 64-TQFP (10x10) |
