Texas Instruments UCC28910DR is a complete insulated gate bipolar transistor (IGBT) based gate-driver solution. This device integrates two high-current gate drivers which can each deliver a continuous source or sink current of 2A and a maximum peak source current of 5A. The UCC28910DR is designed to meet the challenges of driving medium to high power IGBTs, as well as reduce system cost, power loss, and improve reliability. Armed with advanced protection features, the device is capable of providing high levels of safety and robustness to systems in industrial, motor drive, and renewable energy applications.
| Manufacturer | Texas Instruments |
| Product Category | AC DC Converters, Offline Switchers |
| Series | UCC28910 |
| Product | Switching Controllers |
| Packaging | Alternate Packaging |
| Unit-Weight | 0.008960 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 8-SOIC (0.154", 3.90mm Width) 7 leads |
| Operating-Temperature | -40°C ~ 125°C (TJ) |
| Mounting-Type | Surface Mount |
| Supplier-Device-Package | 7-SOIC |
| Watt | 9.5W |
| Number-of-Outputs | 1 Output |
| Output-Isolation | Isolated |
| Internal-Switch-s | Yes |
| Voltage-Breakdown | 700V |
| Topology | Flyback |
| Voltage-Start-Up | 9.5V |
| Voltage-Supply-Vcc-Vdd | 6.5 V ~ 30 V |
| Duty-Cycle | - |
| Frequency-Switching | 420Hz ~ 115kHz |
| Fault-Protection | Current Limiting, Over Temperature, Over Voltage |
| Control-Features | - |
| Shutdown | Yes |
| Isolation | Isolated |
| Maximum Operating Temperature | + 125 C |
| Operating temperature range | - 40 C |
| Switching-Frequency | 115 kHz |
| Package-Case | SOIC-7 |
| Duty-Cycle-Max | 99 % |
UCC28910DR Datasheet
